Kubernetes - NetBox를 kompose로 배포해 보기

Kubernetes v1.24.7 / NetBox v3.4.4 / kompose v1.28.0 / Ubuntu 22.04 LTS

Kubernetes

CLI

개요

  • NetBox는 IPAM(IP Address Management)과 DCIM(DataCenter Infrastructure Management)을 구체적으로 관리하기 위하여 나온 오픈소스이다.
  • helm으로 차트(https://github.com/bootc/netbox-chart)가 존재한다.
  • helm으로도 deployment가 가능은 하지만 env에 대해 전부 수정하기는 힘들고, 구조 상 전부 뜯어 보는 것이 좋다고 생각이 들었다.
  • kompose를 이용하여 manifest 파일을 직접 변환하게 되면 env에 대해 구체적으로 수정이 가능하고, 버전이 고정되어도 좋다 생각하여 진행하게 되었다.
  • NetBox 구성에 들어가는 기본 service들은 다음과 같다.
    1. Redis (included cache)
    2. PostgreSQL
    3. NetBox (included worker)
    4. NetBox-Housekeeping

Manifest 파일 변환 (kompose)

NetBox를 사용하려면 기본적으로 kompose가 설치 되어있어야 한다.
kompose는 docker-compose의 파일을 kubernetes의 manifest로 변환 해주는 플러그인이다.
kompose는 binary 형식으로 쉽게 설치 된다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

# binary
dor1@is-master:~$ curl -L https://github.com/kubernetes/kompose/releases/download/v1.28.0/kompose-linux-amd64 -o kompose
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
  0     0    0     0    0     0      0      0 --:--:-- --:--:-- --:--:--     0
100 19.3M  100 19.3M    0     0  5086k      0  0:00:03  0:00:03 --:--:-- 7024k

# 쓰기 권한 부여
dor1@is-master:~$ chmod +x kompose

# kubectl binary와 같은 위치로 이동
dor1@is-master:~$ sudo mv ./kompose /usr/local/bin

# 확인
dor1@is-master:~$ kompose version
1.28.0 (c4137012e)

kompose설치가 완료 되었다면, netbox-docker의 compose 파일 및 config(python, env) 파일을 k8s manifest 파일로 변경 해준다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106

# source
dor1@is-master:~$ git clone https://github.com/netbox-community/netbox-docker.git
Cloning into 'netbox-docker'...
remote: Enumerating objects: 4070, done.
remote: Counting objects: 100% (4070/4070), done.
remote: Compressing objects: 100% (1658/1658), done.
remote: Total 4070 (delta 2342), reused 3999 (delta 2306), pack-reused 0
Receiving objects: 100% (4070/4070), 1010.18 KiB | 1.53 MiB/s, done.
Resolving deltas: 100% (2342/2342), done.

# move nessesary soruce
dor1@is-master:~$ mkdir netbox
dor1@is-master:~$ cp -r netbox-docker/{configuration,reports,scripts,env,docker-compose.yml} ./netbox
dor1@is-master:~$ cd netbox
dor1@is-master:~/netbox$ ll
total 32
drwxrwxr-x 7 dor1 dor1 4096 Feb 17 17:50 ./
drwxrwxrwx 8 dor1 dor1 4096 Feb 17 17:48 ../
drwxrwxr-x 3 dor1 dor1 4096 Feb 17 17:48 configuration/
-rw-rw-r-- 1 dor1 dor1 2104 Feb 17 17:48 docker-compose.yml
drwxrwxr-x 2 dor1 dor1 4096 Feb 17 17:48 env/
drwxrwxr-x 2 dor1 dor1 4096 Feb 17 17:48 reports/
drwxrwxr-x 2 dor1 dor1 4096 Feb 17 17:48 scripts/

# convert docker-compose to k8s manifest
dor1@is-master:~/netbox$ mkdir kompose
dor1@is-master:~/netbox$ kompose convert -f docker-compose.yml -o kompose
WARN Service "netbox" won't be created because 'ports' is not specified
WARN Volume mount on the host "~/netbox/configuration" isn't supported - ignoring path on the host
WARN Volume mount on the host "~/netbox/reports" isn't supported - ignoring path on the host
WARN Volume mount on the host "~/netbox/scripts" isn't supported - ignoring path on the host
WARN Ignoring user directive. User to be specified as a UID (numeric).
INFO Network netbox-default is detected at Source, shall be converted to equivalent NetworkPolicy at Destination
WARN Service "netbox-housekeeping" won't be created because 'ports' is not specified
WARN Volume mount on the host "~/netbox/configuration" isn't supported - ignoring path on the host
WARN Volume mount on the host "~/netbox/reports" isn't supported - ignoring path on the host
WARN Volume mount on the host "~/netbox/scripts" isn't supported - ignoring path on the host
WARN Ignoring user directive. User to be specified as a UID (numeric).
INFO Network netbox-default is detected at Source, shall be converted to equivalent NetworkPolicy at Destination
WARN Service "netbox-worker" won't be created because 'ports' is not specified
WARN Volume mount on the host "~/netbox/configuration" isn't supported - ignoring path on the host
WARN Volume mount on the host "~/netbox/reports" isn't supported - ignoring path on the host
WARN Volume mount on the host "~/netbox/scripts" isn't supported - ignoring path on the host
WARN Ignoring user directive. User to be specified as a UID (numeric).
INFO Network netbox-default is detected at Source, shall be converted to equivalent NetworkPolicy at Destination
WARN Service "postgres" won't be created because 'ports' is not specified
INFO Network netbox-default is detected at Source, shall be converted to equivalent NetworkPolicy at Destination
WARN Service "redis" won't be created because 'ports' is not specified
INFO Network netbox-default is detected at Source, shall be converted to equivalent NetworkPolicy at Destination
WARN Service "redis-cache" won't be created because 'ports' is not specified
INFO Network netbox-default is detected at Source, shall be converted to equivalent NetworkPolicy at Destination
INFO Kubernetes file "kompose/netbox-deployment.yaml" created
INFO Kubernetes file "kompose/env-netbox-env-configmap.yaml" created
INFO Kubernetes file "kompose/netbox-claim0-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/netbox-claim1-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/netbox-claim2-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/netbox-media-files-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/netbox-default-networkpolicy.yaml" created
INFO Kubernetes file "kompose/netbox-housekeeping-deployment.yaml" created
INFO Kubernetes file "kompose/netbox-housekeeping-claim0-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/netbox-housekeeping-claim1-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/netbox-housekeeping-claim2-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/netbox-worker-deployment.yaml" created
INFO Kubernetes file "kompose/netbox-worker-claim0-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/netbox-worker-claim1-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/netbox-worker-claim2-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/postgres-deployment.yaml" created
INFO Kubernetes file "kompose/env-postgres-env-configmap.yaml" created
INFO Kubernetes file "kompose/netbox-postgres-data-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/redis-deployment.yaml" created
INFO Kubernetes file "kompose/env-redis-env-configmap.yaml" created
INFO Kubernetes file "kompose/netbox-redis-data-persistentvolumeclaim.yaml" created
INFO Kubernetes file "kompose/redis-cache-deployment.yaml" created
INFO Kubernetes file "kompose/env-redis-cache-env-configmap.yaml" created
INFO Kubernetes file "kompose/netbox-redis-cache-data-persistentvolumeclaim.yaml" created

# 확인
dor1@is-master:~/netbox$ cd kompose
dor1@is-master:~/netbox/kompose$ ll
total 128
drwxrwxr-x 2 dor1 dor1 4096 Feb 21 09:57 ./
drwxrwxr-x 7 dor1 dor1 4096 Feb 17 17:50 ../
-rw-r--r-- 1 dor1 dor1 1271 Feb 17 17:50 env-netbox-env-configmap.yaml
-rw-r--r-- 1 dor1 dor1  242 Feb 17 17:50 env-postgres-env-configmap.yaml
-rw-r--r-- 1 dor1 dor1  206 Feb 17 17:50 env-redis-cache-env-configmap.yaml
-rw-r--r-- 1 dor1 dor1  181 Feb 17 17:50 env-redis-env-configmap.yaml
-rw-r--r-- 1 dor1 dor1  248 Feb 17 17:50 netbox-claim0-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  248 Feb 17 17:50 netbox-claim1-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  248 Feb 17 17:50 netbox-claim2-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  325 Feb 17 17:50 netbox-default-networkpolicy.yaml
-rw-r--r-- 1 dor1 dor1 8373 Feb 17 17:50 netbox-deployment.yaml
-rw-r--r-- 1 dor1 dor1  274 Feb 17 17:50 netbox-housekeeping-claim0-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  274 Feb 17 17:50 netbox-housekeeping-claim1-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  274 Feb 17 17:50 netbox-housekeeping-claim2-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1 8624 Feb 17 17:50 netbox-housekeeping-deployment.yaml
-rw-r--r-- 1 dor1 dor1  259 Feb 17 17:50 netbox-media-files-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  263 Feb 17 17:50 netbox-postgres-data-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  269 Feb 17 17:50 netbox-redis-cache-data-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  309 Feb 17 17:50 netbox-redis-data-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  262 Feb 17 17:50 netbox-worker-claim0-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  262 Feb 17 17:50 netbox-worker-claim1-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1  262 Feb 17 17:50 netbox-worker-claim2-persistentvolumeclaim.yaml
-rw-r--r-- 1 dor1 dor1 8602 Feb 17 17:50 netbox-worker-deployment.yaml
-rw-r--r-- 1 dor1 dor1 1584 Feb 17 17:50 postgres-deployment.yaml
-rw-r--r-- 1 dor1 dor1 1358 Feb 17 17:50 redis-cache-deployment.yaml
-rw-r--r-- 1 dor1 dor1 1321 Feb 17 17:50 redis-deployment.yaml

변환된 파일들을 application 별로 정리하자면 다음과 같다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31

NetBox(Application)
- netbox-default-networkpolicy.yaml
- netbox-deployment.yaml
- env-netbox-env-configmap.yaml
- netbox-claim0-persistentvolumeclaim.yaml
- netbox-claim1-persistentvolumeclaim.yaml
- netbox-claim2-persistentvolumeclaim.yaml
- netbox-media-files-persistentvolumeclaim.yaml

- netbox-housekeeping-deployment.yaml
- netbox-housekeeping-claim0-persistentvolumeclaim.yaml
- netbox-housekeeping-claim1-persistentvolumeclaim.yaml
- netbox-housekeeping-claim2-persistentvolumeclaim.yaml

- netbox-worker-deployment.yaml
- netbox-worker-claim0-persistentvolumeclaim.yaml
- netbox-worker-claim1-persistentvolumeclaim.yaml
- netbox-worker-claim2-persistentvolumeclaim.yaml

PostgreSQL(DB)
- postgres-deployment.yaml
- env-postgres-env-configmap.yaml
- netbox-postgres-data-persistentvolumeclaim.yaml

Redis(Task queue, Cache)
- redis-deployment.yaml
- redis-cache-deployment.yaml
- env-redis-env-configmap.yaml
- env-redis-cache-env-configmap.yaml
- netbox-redis-data-persistentvolumeclaim.yaml
- netbox-redis-cache-data-persistentvolumeclaim.yaml

rook-ceph을 PVC로 이용하는 manifest 만들기

Deployment 전 서비스들에서 필요 없는 내용들을 하나하나 변경 해준다.
전체적으로 필요 없는 정의는 다음과 같다.

  • annotations
  • creationTimestamp
  • status

Service 접근을 위하여 각각의 deployment에서 port expose 해준다.
PVC가 사용되는 내용은 rook-ceph으로 변경 해준다.
namespace를 추가하여 default와 분리해준다.
configMap에 들어가 있는 내용 중 Password가 들어가 있는 파트는 보안을 위해 Secret으로 변경해준다.
Secret으로 바꾸는 이유는 configMap보다는 Secret에서는 base1-encoded로 한번 더 암호화 되기 때문이다.

1. Redis / RedisCache

configMap to Secret

Redis와 RedisCache의 configMap에 들어가 있는 내용은 Password가 다 이므로 내용과 파일 이름을 바꾼다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31

# env-redis-env-secret.yaml
dor1@is-master:~/netbox/kompose$ mv env-redis-env-configmap.yaml env-redis-env-secret.yaml
dor1@is-master:~/netbox/kompose$ vi env-redis-env-secret.yaml
apiVersion: v1
data:
  REDIS_PASSWORD: YW9vbmkzNjUhQA==
# ConfigMap -> Secret
kind: Secret
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: redis-env-redis-env
  name: env-redis-env
  # Add namespace
  namespace: netbox

# env-redis-cache-env-secret.yaml
dor1@is-master:~/netbox/kompose$ mv env-redis-cache-env-configmap.yaml env-redis-cache-env-secret.yaml
dor1@is-master:~/netbox/kompose$ vi env-redis-cache-env-secret.yaml
apiVersion: v1
data:
  REDIS_PASSWORD: YW9vbmkzNjUhQA==
# ConfigMap -> Secret
kind: Secret
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: redis-cache-env-redis-cache-env
  name: env-redis-cache-env
  # Add namespace
  namespace: netbox

PVC

PVC는 rook-ceph을 사용한다.
용량은 넉넉하게 50Gi로 설정 한다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43

# netbox-redis-data-persistentvolumeclaim.yaml
dor1@is-master:~/netbox/kompose$ vi netbox-redis-data-persistentvolumeclaim.yaml
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox-redis-data
  name: netbox-redis-data
  # Add namespace
  namespace: netbox
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      # 100Mi -> 50Gi
      storage: 50Gi
  # Add storageClass
  storageClassName: rook-cephfs
#status: {}

# netbox-redis-cache-data-persistentvolumeclaim.yaml
dor1@is-master:~/netbox/kompose$ vi netbox-redis-cache-data-persistentvolumeclaim.yaml
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox-redis-cache-data
  name: netbox-redis-cache-data
  # Add namespace
  namespace: netbox
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      # 100Mi -> 50Gi
      storage: 50Gi
  # Add storageClass
  storageClassName: rook-cephfs
#status: {}

Deployment

configMapkeyRef → secretKeyRef
Redis와 RedisCache의 expose port를 설정한다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58

# redis-deployment.yaml
dor1@is-master:~/netbox/kompose$ vi redis-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  #annotations:
  #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
  #  kompose.version: 1.28.0 (c4137012e)
  #creationTimestamp: null
  labels:
    io.kompose.service: redis
  name: redis
  # Add namespace
  namespace: netbox
spec:
  replicas: 1
  selector:
    matchLabels:
      io.kompose.service: redis
  strategy:
    type: Recreate
  template:
    metadata:
      #annotations:
      #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
      #  kompose.version: 1.28.0 (c4137012e)
      #creationTimestamp: null
      labels:
        io.kompose.network/netbox-default: "true"
        io.kompose.service: redis
    spec:
      containers:
        - args:
            - sh
            - -c
            - redis-server --appendonly yes --requirepass $REDIS_PASSWORD
          env:
            - name: REDIS_PASSWORD
              valueFrom:
                # configMap -> secret
                secretKeyRef:
                  key: REDIS_PASSWORD
                  name: env-redis-env
          image: redis:7-alpine
          name: redis
          # Expose redis serviceport
          ports:
          - containerPort: 6379
          resources: {}
          volumeMounts:
            - mountPath: /data
              name: netbox-redis-data
      restartPolicy: Always
      volumes:
        - name: netbox-redis-data
          persistentVolumeClaim:
            claimName: netbox-redis-data
#status: {}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58

# redis-cache-deployment.yaml
dor1@is-master:~/netbox/kompose$ vi redis-cache-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  #annotations:
  #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
  #  kompose.version: 1.28.0 (c4137012e)
  #creationTimestamp: null
  labels:
    io.kompose.service: redis-cache
  name: redis-cache
  # Add namespace
  namespace: netbox
spec:
  replicas: 1
  selector:
    matchLabels:
      io.kompose.service: redis-cache
  strategy:
    type: Recreate
  template:
    metadata:
      #annotations:
      #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
      #  kompose.version: 1.28.0 (c4137012e)
      #creationTimestamp: null
      labels:
        io.kompose.network/netbox-default: "true"
        io.kompose.service: redis-cache
    spec:
      containers:
        - args:
            - sh
            - -c
            - redis-server --requirepass $REDIS_PASSWORD
          env:
            - name: REDIS_PASSWORD
              valueFrom:
                # configMap -> secret
                secretKeyRef:
                  key: REDIS_PASSWORD
                  name: env-redis-cache-env
          image: redis:7-alpine
          name: redis-cache
          # Expose redis-cache serviceport
          ports:
          - containerPort: 6379
          resources: {}
          volumeMounts:
            - mountPath: /data
              name: netbox-redis-cache-data
      restartPolicy: Always
      volumes:
        - name: netbox-redis-cache-data
          persistentVolumeClaim:
            claimName: netbox-redis-cache-data
#status: {}

Redis / RedisCache Deployment

설정이 완료 되었으면 이후 Redis에 대하여 배포를 해준다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39

# namespace 생성
dor1@is-master:~/netbox/kompose$ kubectl create ns netbox
namespace/netbox created

# configMap
dor1@is-master:~/netbox/kompose$ kubectl apply -f env-redis-env-secret.yaml -f env-redis-cache-env-secret.yaml
secret/env-redis-env created
secret/env-redis-cache-env created

# PVC
dor1@is-master:~/netbox/kompose$ kubectl apply -f netbox-redis-data-persistentvolumeclaim.yaml -f netbox-redis-cache-data-persistentvolumeclaim.yaml
persistentvolumeclaim/netbox-redis-data created
persistentvolumeclaim/netbox-redis-cache-data created

# Deployment
dor1@is-master:~/netbox/kompose$ kubectl apply -f redis-deployment.yaml -f redis-cache-deployment.yaml
deployment.apps/redis created
deployment.apps/redis-cache created

# 확인
dor1@is-master:~/netbox/kompose$ kubectl get cm,secret,pvc,pod,deployments -n netbox
NAME                         DATA   AGE
configmap/kube-root-ca.crt   1      25h

NAME                         TYPE     DATA   AGE
secret/env-redis-cache-env   Opaque   1      4m33s
secret/env-redis-env         Opaque   1      4m33s

NAME                                            STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   AGE
persistentvolumeclaim/netbox-redis-cache-data   Bound    pvc-122031da-f54a-4aac-b448-72a4a841781c   50Gi       RWO            rook-cephfs    4m33s
persistentvolumeclaim/netbox-redis-data         Bound    pvc-5ce73c26-bb69-493b-88d0-ee05044a4716   50Gi       RWO            rook-cephfs    4m33s

NAME                             READY   STATUS    RESTARTS   AGE
pod/redis-86677c4cf5-tvtdf       1/1     Running   0          4m33s
pod/redis-cache-9d9b9c48-vgh7r   1/1     Running   0          4m33s

NAME                          READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/redis         1/1     1            1           4m33s
deployment.apps/redis-cache   1/1     1            1           4m33s

2. PostgreSQL

configMap to Secret

PostgreSQL 또한 configMap에 들어가 있는 내용은 Password가 다 이므로 내용과 파일 이름을 바꾼다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

# env-postgres-env-secret.yaml
dor1@is-master:~/netbox/kompose$ mv env-postgres-env-configmap.yaml env-postgres-env-secret.yaml
dor1@is-master:~/netbox/kompose$ vi env-postgres-env-secret.yaml
apiVersion: v1
data:
  POSTGRES_DB: bmV0Ym94
  POSTGRES_PASSWORD: YW9vbmkzNjUhQA==
  POSTGRES_USER: bmV0Ym94
# ConfigMap -> Secret
kind: Secret
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: postgres-env-postgres-env
  name: env-postgres-env
  # Add namespace
  namespace: netbox

PVC

PVC는 rook-ceph을 사용한다.
용량은 DB이다 보니 500Gi로 크게 설정한다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21

# netbox-postgres-data-persistentvolumeclaim.yaml
dor1@is-master:~/netbox/kompose$ vi netbox-postgres-data-persistentvolumeclaim.yaml
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox-postgres-data
  name: netbox-postgres-data
  # Add namespace
  namespace: netbox
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      # 100Mi -> 500Gi
      storage: 500Gi
  # Add storageClass
  storageClassName: rook-cephfs
#status: {}

Deployment

configMapkeyRef → secretKeyRef
PostgreSQL의 expose port를 설정한다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66

# postgres-deployment.yaml
dor1@is-master:~/netbox/kompose$ vi postgres-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  #annotations:
  #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
  #  kompose.version: 1.28.0 (c4137012e)
  #creationTimestamp: null
  labels:
    io.kompose.service: postgres
  name: postgres
  # Add namespace
  namespace: netbox
spec:
  replicas: 1
  selector:
    matchLabels:
      io.kompose.service: postgres
  strategy:
    type: Recreate
  template:
    metadata:
      #annotations:
      #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
      #  kompose.version: 1.28.0 (c4137012e)
      #creationTimestamp: null
      labels:
        io.kompose.network/netbox-default: "true"
        io.kompose.service: postgres
    spec:
      containers:
        - env:
            - name: POSTGRES_DB
              valueFrom:
                # configMap -> secret
                secretKeyRef:
                  key: POSTGRES_DB
                  name: env-postgres-env
            - name: POSTGRES_PASSWORD
              valueFrom:
                # configMap -> secret
                secretKeyRef:
                  key: POSTGRES_PASSWORD
                  name: env-postgres-env
            - name: POSTGRES_USER
              valueFrom:
                 # configMap -> secret
                secretKeyRef:
                  key: POSTGRES_USER
                  name: env-postgres-env
          image: postgres:15-alpine
          name: postgres
          # Expose postgresql serviceport
          ports:
          - containerPort: 5432
          resources: {}
          volumeMounts:
            - mountPath: /var/lib/postgresql/data
              name: netbox-postgres-data
      restartPolicy: Always
      volumes:
        - name: netbox-postgres-data
          persistentVolumeClaim:
            claimName: netbox-postgres-data
#status: {}

PostgreSQL Deployment

설정이 완료 되었으면 이후 PostgreSQL에 대하여 배포를 해준다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36

# configMap
dor1@is-master:~/netbox/kompose$ kubectl apply -f env-postgres-env-secret.yaml
secret/env-postgres-env created

# PVC
dor1@is-master:~/netbox/kompose$ kubectl apply -f netbox-postgres-data-persistentvolumeclaim.yaml
persistentvolumeclaim/netbox-postgres-data created

# Deployment
dor1@is-master:~/netbox/kompose$ kubectl apply -f postgres-deployment.yaml
deployment.apps/postgres created

# 확인
dor1@is-master:~/netbox/kompose$ kubectl get cm,secret,pvc,pod,deployments -n netbox
NAME                         DATA   AGE
configmap/kube-root-ca.crt   1      26h

NAME                         TYPE     DATA   AGE
secret/env-postgres-env      Opaque   3      4m8s
secret/env-redis-cache-env   Opaque   1      20m
secret/env-redis-env         Opaque   1      20m

NAME                                            STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   AGE
persistentvolumeclaim/netbox-postgres-data      Bound    pvc-c9ab32be-8ac8-48f1-bf5e-d99901938edb   500Gi      RWO            rook-cephfs    6m17s
persistentvolumeclaim/netbox-redis-cache-data   Bound    pvc-122031da-f54a-4aac-b448-72a4a841781c   50Gi       RWO            rook-cephfs    20m
persistentvolumeclaim/netbox-redis-data         Bound    pvc-5ce73c26-bb69-493b-88d0-ee05044a4716   50Gi       RWO            rook-cephfs    20m

NAME                             READY   STATUS    RESTARTS   AGE
pod/postgres-856f47bdbf-bts8j    1/1     Running   0          6m17s
pod/redis-86677c4cf5-tvtdf       1/1     Running   0          20m
pod/redis-cache-9d9b9c48-vgh7r   1/1     Running   0          20m

NAME                          READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/postgres      1/1     1            1           6m17s
deployment.apps/redis         1/1     1            1           20m
deployment.apps/redis-cache   1/1     1            1           20m

3. NetBox

netbox와 netbox-worker는 하나의 패키지 형태로 같이 작업 해준다.

configMap & Secret

configMap과 Secret은 관리를 위해 분리한다.
POD 간 통신을 위해 expose 되어있는 port 부분도 변수로 설정한다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60

# env-netbox-env-configmap.yaml
dor1@is-master:~/netbox/kompose$ vi env-netbox-env-configmap.yaml
apiVersion: v1
data:
  CORS_ORIGIN_ALLOW_ALL: "True"
  DB_HOST: postgres
  # Add postgresql serviceport
  DB_PORT: "5432"
  DB_NAME: netbox
  DB_USER: netbox
  # Unnecessary
  #DB_PASSWORD:
  EMAIL_FROM: netbox@bar.com
  # Secret
  #EMAIL_PASSWORD:
  EMAIL_PORT: "25"
  EMAIL_SERVER: localhost
  EMAIL_SSL_CERTFILE: ""
  EMAIL_SSL_KEYFILE: ""
  EMAIL_TIMEOUT: "5"
  EMAIL_USE_SSL: "false"
  EMAIL_USE_TLS: "false"
  EMAIL_USERNAME: netbox
  GRAPHQL_ENABLED: "true"
  HOUSEKEEPING_INTERVAL: "86400"
  MEDIA_ROOT: /opt/netbox/netbox/media
  METRICS_ENABLED: "false"
  REDIS_CACHE_DATABASE: "1"
  REDIS_CACHE_HOST: redis-cache
  # Add redis-cache serviceport
  REDIS_CACHE_PORT: "6379"
  REDIS_CACHE_INSECURE_SKIP_TLS_VERIFY: "false"
  REDIS_CACHE_SSL: "false"
  REDIS_DATABASE: "0"
  REDIS_HOST: redis
  # Add redis serviceport
  REDIS_PORT: "6379"
  REDIS_INSECURE_SKIP_TLS_VERIFY: "false"
  REDIS_SSL: "false"
  RELEASE_CHECK_URL: https://api.github.com/repos/netbox-community/netbox/releases
  # Secret
  #SECRET_KEY:
  SKIP_SUPERUSER: "false"
  # Secret
  #SUPERUSER_API_TOKEN:
  SUPERUSER_EMAIL: admin@example.com
  SUPERUSER_NAME: admin
  # Secret
  #SUPERUSER_PASSWORD:
  WEBHOOKS_ENABLED: "true"
  # Add for TZ
  TIME_ZONE: "Asia/Seoul"
kind: ConfigMap
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox-env-netbox-env
  name: env-netbox-env
  # Add namespace
  namespace: netbox

1
2
3
4
5
6
7
8
9
10
11
12
13
14

# NEW [env-netbox-env-secret.yaml]
dor1@is-master:~/netbox/kompose$ vi env-netbox-env-secret.yaml
apiVersion: v1
kind: Secret
metadata:
  labels:
    io.kompose.service: netbox-env-netbox-env
  name: env-netbox-env
  namespace: netbox
data:
  EMAIL_PASSWORD: IA==
  SECRET_KEY: cjhPd0R6bmohIWRjaSNQOWdobVJmZHUxWXN4bTBBaVBlRENRaEtFK05fckNsZldOag==
  SUPERUSER_API_TOKEN: MDEyMzQ1Njc4OWFiY2RlZjAxMjM0NTY3ODlhYmNkZWYwMTIzNDU2Nw==
  SUPERUSER_PASSWORD: YWRtaW4=

networkPolicy

networkPolicy는 policyType을 따라 기본적으로 egress와 ingress에만 적용되기 때문에 Labels에 적용된 대상만 접근이 가능하다.
Cloud와 같이 public망을 사용하지 않는다면, on-premises(legacy) 환경에서 NAT처리로 인하여 사용 할 일이 없기 때문에NetworkPolicy는 지워줘도 된다.

1
2

# Delete networkPolicy yaml
dor1@is-master:~/netbox/kompose$ rm netbox-default-networkpolicy.yaml

PVC

docker-compose에서 변환한 PVC가 3개로 되어있는데, Deployment에서 보게 되면 volumeMount 항목으로 ReadOnly 되어있다.
PVC의 항목들은 하나의 파일로 합친 후 netbox-worker와 netbox-housekeeping 같이 사용하면 config가 공유된다. (claim에 대한 volumeMount 항목이 같음)
netbox-media-files-persistentvolumeclaim.yaml은 media 파일 특성 상 별도로 관리한다.
PVC는 rook-ceph을 사용한다. netbox의 용량은 설정 값을 고려하여 50Gi로 설정한다.
netbox-media-files는 media 파일 특성 상 500Gi 이상 크게 잡는다.
rook-ceph으로 바꾸는 과정에서 rook-ceph.cephfs.CSI 드라이버는 ROX(ReadOnlyMany)를 지원하지 않기에 RWX(ReadWriteMany)로 변경한다. (netbox-media-files는 공통적으로 사용하기에 RXO 상태로 유지)
https://rook.io/docs/rook/latest/Getting-Started/quickstart/#storage

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76

# Merge contents
dor1@is-master:~/netbox/kompose$ cat netbox-claim[0-2]-persistentvolumeclaim.yaml > netbox-persistentvolumeclaim.yaml
dor1@is-master:~/netbox/kompose$ rm netbox-claim[0-2]-persistentvolumeclaim.yaml netbox-worker-claim[0-2]-persistentvolumeclaim.yaml

# netbox-persistentvolumeclaim.yaml
dor1@is-master:~/netbox/kompose$ vi netbox-persistentvolumeclaim.yaml
# [netbox-claim0-persistentvolumeclaim.yaml]
# for /etc/netbox/config
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox-claim0
  name: netbox-claim0
  # Add namespace
  namespace: netbox
spec:
  accessModes:
    # ROX -> RWX
    - ReadWriteMany
  resources:
    requests:
      # 100Mi -> 50Gi
      storage: 50Gi
  # Add storageClass
  storageClassName: rook-cephfs
#status: {}

# Add divider [netbox-claim1-persistentvolumeclaim.yaml]
# for /etc/netbox/reports
---
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox-claim1
  name: netbox-claim1
  # Add namespace
  namespace: netbox
spec:
  accessModes:
    # ROX -> RWX
    - ReadWriteMany
  resources:
    requests:
      # 100Mi -> 50Gi
      storage: 50Gi
  # Add storageClass
  storageClassName: rook-cephfs
#status: {}

# Add divider [netbox-claim2-persistentvolumeclaim.yaml]
# for /etc/netbox/scripts
---
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox-claim2
  name: netbox-claim2
  # Add namespace
  namespace: netbox
spec:
  accessModes:
    # ROX -> RWX
    - ReadWriteMany
  resources:
    requests:
      # 100Mi -> 50Gi
      storage: 50Gi
  # Add storageClass
  storageClassName: rook-cephfs
#status: {}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21

# netbox-media-files-persistentvolumeclaim.yaml
dor1@is-master:~/netbox/kompose$ vi netbox-media-files-persistentvolumeclaim.yaml
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox-media-files
  name: netbox-media-files
  # Add namespace
  namespace: netbox
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      # 100Mi -> 500Gi
      storage: 500Gi
  # Add storageClass
  storageClassName: rook-cephfs
#status: {}

Deployment

PVC의 통합을 진행하기 때문에 netbox-worker의 PVC는 netbox-claim으로 변경한다.
NetBox 항목은 접근을 위하여 expose port 설정한다.
이미지의 버전을 고정한다.
configMapkeyRef → secretKeyRef (Secret 분리 사항만)
Redis 및 PostgreSQL에 대한 항목은 expose 되어있는 port가 있으므로 접근을 위해 항목 추가한다.
k8s 특성 상 liveness(docker의 helathcheck와 유사한 기능)은 새로 path를 설정 해줘야 하며, 필요 없을 시에는 사용할 필요가 없다. (기본 이미지로 진행하게 되면 기본적으로 설정 되어있어Events의 항목에 error가 지속적으로 발생함)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297

# netbox-deployment.yaml
dor1@is-master:~/netbox/kompose$ vi netbox-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  #annotations:
  #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
  #  kompose.version: 1.28.0 (c4137012e)
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox
  name: netbox
  # Add namespace
  namespace: netbox
spec:
  replicas: 1
  selector:
    matchLabels:
      io.kompose.service: netbox
  strategy:
    type: Recreate
  template:
    metadata:
      #annotations:
      #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
      #  kompose.version: 1.28.0 (c4137012e)
      #creationTimestamp: null
      labels:
        io.kompose.network/netbox-default: "true"
        io.kompose.service: netbox
    spec:
      containers:
        - env:
            - name: CORS_ORIGIN_ALLOW_ALL
              valueFrom:
                configMapKeyRef:
                  key: CORS_ORIGIN_ALLOW_ALL
                  name: env-netbox-env
            - name: DB_HOST
              valueFrom:
                configMapKeyRef:
                  key: DB_HOST
                  name: env-netbox-env
            # Added for DB_PORT
            - name: DB_PORT
              valueFrom:
                configMapKeyRef:
                  key: DB_PORT
                  name: env-netbox-env
            - name: DB_NAME
              valueFrom:
                configMapKeyRef:
                  key: DB_NAME
                  name: env-netbox-env
            - name: DB_USER
              valueFrom:
                configMapKeyRef:
                  key: DB_USER
                  name: env-netbox-env
            # configMap -> secret
            # Used env-postgres-env
            - name: DB_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: POSTGRES_PASSWORD
                  name: env-postgres-env
            - name: EMAIL_FROM
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_FROM
                  name: env-netbox-env
            # configMap -> secret
            - name: EMAIL_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: EMAIL_PASSWORD
                  name: env-netbox-env
            - name: EMAIL_PORT
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_PORT
                  name: env-netbox-env
            - name: EMAIL_SERVER
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_SERVER
                  name: env-netbox-env
            - name: EMAIL_SSL_CERTFILE
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_SSL_CERTFILE
                  name: env-netbox-env
            - name: EMAIL_SSL_KEYFILE
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_SSL_KEYFILE
                  name: env-netbox-env
            - name: EMAIL_TIMEOUT
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_TIMEOUT
                  name: env-netbox-env
            - name: EMAIL_USERNAME
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_USERNAME
                  name: env-netbox-env
            - name: EMAIL_USE_SSL
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_USE_SSL
                  name: env-netbox-env
            - name: EMAIL_USE_TLS
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_USE_TLS
                  name: env-netbox-env
            - name: GRAPHQL_ENABLED
              valueFrom:
                configMapKeyRef:
                  key: GRAPHQL_ENABLED
                  name: env-netbox-env
            - name: HOUSEKEEPING_INTERVAL
              valueFrom:
                configMapKeyRef:
                  key: HOUSEKEEPING_INTERVAL
                  name: env-netbox-env
            - name: MEDIA_ROOT
              valueFrom:
                configMapKeyRef:
                  key: MEDIA_ROOT
                  name: env-netbox-env
            - name: METRICS_ENABLED
              valueFrom:
                configMapKeyRef:
                  key: METRICS_ENABLED
                  name: env-netbox-env
            - name: REDIS_CACHE_DATABASE
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_DATABASE
                  name: env-netbox-env
            - name: REDIS_CACHE_HOST
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_HOST
                  name: env-netbox-env
            # Added for REDIS_CACHE_PORT
            - name: REDIS_CACHE_PORT
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_PORT
                  name: env-netbox-env
            - name: REDIS_CACHE_INSECURE_SKIP_TLS_VERIFY
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_INSECURE_SKIP_TLS_VERIFY
                  name: env-netbox-env
            # configMap -> secret
            # REDIS_CACHE_PASSWROD -> REDIS_PASSWORD
            # Used env-redis-cache-env
            - name: REDIS_CACHE_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: REDIS_PASSWORD
                  name: env-redis-cache-env
            - name: REDIS_CACHE_SSL
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_SSL
                  name: env-netbox-env
            - name: REDIS_DATABASE
              valueFrom:
                configMapKeyRef:
                  key: REDIS_DATABASE
                  name: env-netbox-env
            - name: REDIS_HOST
              valueFrom:
                configMapKeyRef:
                  key: REDIS_HOST
                  name: env-netbox-env
            # Added for REDIS_PORT
            - name: REDIS_PORT
              valueFrom:
                configMapKeyRef:
                  key: REDIS_PORT
                  name: env-netbox-env
            - name: REDIS_INSECURE_SKIP_TLS_VERIFY
              valueFrom:
                configMapKeyRef:
                  key: REDIS_INSECURE_SKIP_TLS_VERIFY
                  name: env-netbox-env
            # configMap -> secret
            # Used env-redis-env
            - name: REDIS_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: REDIS_PASSWORD
                  name: env-redis-env
            - name: REDIS_SSL
              valueFrom:
                configMapKeyRef:
                  key: REDIS_SSL
                  name: env-netbox-env
            - name: RELEASE_CHECK_URL
              valueFrom:
                configMapKeyRef:
                  key: RELEASE_CHECK_URL
                  name: env-netbox-env
            # configMap -> secret
            - name: SECRET_KEY
              valueFrom:
                secretKeyRef:
                  key: SECRET_KEY
                  name: env-netbox-env
            - name: SKIP_SUPERUSER
              valueFrom:
                configMapKeyRef:
                  key: SKIP_SUPERUSER
                  name: env-netbox-env
            # configMap -> secret
            - name: SUPERUSER_API_TOKEN
              valueFrom:
                secretKeyRef:
                  key: SUPERUSER_API_TOKEN
                  name: env-netbox-env
            - name: SUPERUSER_EMAIL
              valueFrom:
                configMapKeyRef:
                  key: SUPERUSER_EMAIL
                  name: env-netbox-env
            - name: SUPERUSER_NAME
              valueFrom:
                configMapKeyRef:
                  key: SUPERUSER_NAME
                  name: env-netbox-env
            # configMap -> secret
            - name: SUPERUSER_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: SUPERUSER_PASSWORD
                  name: env-netbox-env
            - name: WEBHOOKS_ENABLED
              valueFrom:
                configMapKeyRef:
                  key: WEBHOOKS_ENABLED
                  name: env-netbox-env
            # Added for TZ
            - name: TIME_ZONE
              valueFrom:
                configMapKeyRef:
                  key: TIME_ZONE
                  name: env-netbox-env
          # Fixed version
          image: netboxcommunity/netbox:v3.4-2.4.0
          #livenessProbe:
          #  exec:
          #    command:
          #      - curl -f http://localhost:8080/api/ || exit 1
          #  initialDelaySeconds: 60
          #  periodSeconds: 15
          #  timeoutSeconds: 3
          name: netbox
          # Expose netbox serviceport
          ports:
          - containerPort: 8080
          resources: {}
          volumeMounts:
            - mountPath: /etc/netbox/config
              name: netbox-claim0
              readOnly: true
            - mountPath: /etc/netbox/reports
              name: netbox-claim1
              readOnly: true
            - mountPath: /etc/netbox/scripts
              name: netbox-claim2
              readOnly: true
            - mountPath: /opt/netbox/netbox/media
              name: netbox-media-files
      restartPolicy: Always
      volumes:
        - name: netbox-claim0
          persistentVolumeClaim:
            claimName: netbox-claim0
            readOnly: true
        - name: netbox-claim1
          persistentVolumeClaim:
            claimName: netbox-claim1
            readOnly: true
        - name: netbox-claim2
          persistentVolumeClaim:
            claimName: netbox-claim2
            readOnly: true
        - name: netbox-media-files
          persistentVolumeClaim:
            claimName: netbox-media-files
#status: {}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301

# netbox-worker-deployment.yaml
dor1@is-master:~/netbox/kompose$ vi netbox-worker-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  #annotations:
  #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
  #  kompose.version: 1.28.0 (c4137012e)
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox-worker
  name: netbox-worker
  # Add namespace
  namespace: netbox
spec:
  replicas: 1
  selector:
    matchLabels:
      io.kompose.service: netbox-worker
  strategy:
    type: Recreate
  template:
    metadata:
      #annotations:
      #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
      #  kompose.version: 1.28.0 (c4137012e)
      #creationTimestamp: null
      labels:
        io.kompose.network/netbox-default: "true"
        io.kompose.service: netbox-worker
    spec:
      containers:
        - args:
            - /opt/netbox/venv/bin/python
            - /opt/netbox/netbox/manage.py
            - rqworker
          env:
            - name: CORS_ORIGIN_ALLOW_ALL
              valueFrom:
                configMapKeyRef:
                  key: CORS_ORIGIN_ALLOW_ALL
                  name: env-netbox-env
            - name: DB_HOST
              valueFrom:
                configMapKeyRef:
                  key: DB_HOST
                  name: env-netbox-env
            # Added for DB_PORT
            - name: DB_PORT
              valueFrom:
                configMapKeyRef:
                  key: DB_PORT
                  name: env-netbox-env
            - name: DB_NAME
              valueFrom:
                configMapKeyRef:
                  key: DB_NAME
                  name: env-netbox-env
            - name: DB_USER
              valueFrom:
                configMapKeyRef:
                  key: DB_USER
                  name: env-netbox-env
            # configMap -> secret
            # Used env-postgres-env
            - name: DB_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: POSTGRES_PASSWORD
                  name: env-postgres-env
            - name: EMAIL_FROM
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_FROM
                  name: env-netbox-env
            # configMap -> secret
            - name: EMAIL_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: EMAIL_PASSWORD
                  name: env-netbox-env
            - name: EMAIL_PORT
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_PORT
                  name: env-netbox-env
            - name: EMAIL_SERVER
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_SERVER
                  name: env-netbox-env
            - name: EMAIL_SSL_CERTFILE
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_SSL_CERTFILE
                  name: env-netbox-env
            - name: EMAIL_SSL_KEYFILE
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_SSL_KEYFILE
                  name: env-netbox-env
            - name: EMAIL_TIMEOUT
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_TIMEOUT
                  name: env-netbox-env
            - name: EMAIL_USERNAME
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_USERNAME
                  name: env-netbox-env
            - name: EMAIL_USE_SSL
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_USE_SSL
                  name: env-netbox-env
            - name: EMAIL_USE_TLS
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_USE_TLS
                  name: env-netbox-env
            - name: GRAPHQL_ENABLED
              valueFrom:
                configMapKeyRef:
                  key: GRAPHQL_ENABLED
                  name: env-netbox-env
            - name: HOUSEKEEPING_INTERVAL
              valueFrom:
                configMapKeyRef:
                  key: HOUSEKEEPING_INTERVAL
                  name: env-netbox-env
            - name: MEDIA_ROOT
              valueFrom:
                configMapKeyRef:
                  key: MEDIA_ROOT
                  name: env-netbox-env
            - name: METRICS_ENABLED
              valueFrom:
                configMapKeyRef:
                  key: METRICS_ENABLED
                  name: env-netbox-env
            - name: REDIS_CACHE_DATABASE
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_DATABASE
                  name: env-netbox-env
            - name: REDIS_CACHE_HOST
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_HOST
                  name: env-netbox-env
            # Added for REDIS_CACHE_PORT
            - name: REDIS_CACHE_PORT
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_PORT
                  name: env-netbox-env
            - name: REDIS_CACHE_INSECURE_SKIP_TLS_VERIFY
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_INSECURE_SKIP_TLS_VERIFY
                  name: env-netbox-env
            # configMap -> secret
            # REDIS_CACHE_PASSWROD -> REDIS_PASSWORD
            # Used env-redis-cache-env
            - name: REDIS_CACHE_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: REDIS_PASSWORD
                  name: env-redis-cache-env
            - name: REDIS_CACHE_SSL
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_SSL
                  name: env-netbox-env
            - name: REDIS_DATABASE
              valueFrom:
                configMapKeyRef:
                  key: REDIS_DATABASE
                  name: env-netbox-env
            - name: REDIS_HOST
              valueFrom:
                configMapKeyRef:
                  key: REDIS_HOST
                  name: env-netbox-env
            # Added for REDIS_PORT
            - name: REDIS_PORT
              valueFrom:
                configMapKeyRef:
                  key: REDIS_PORT
                  name: env-netbox-env
            - name: REDIS_INSECURE_SKIP_TLS_VERIFY
              valueFrom:
                configMapKeyRef:
                  key: REDIS_INSECURE_SKIP_TLS_VERIFY
                  name: env-netbox-env
            # configMap -> secret
            # Used env-redis-env
            - name: REDIS_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: REDIS_PASSWORD
                  name: env-redis-env
            - name: REDIS_SSL
              valueFrom:
                configMapKeyRef:
                  key: REDIS_SSL
                  name: env-netbox-env
            - name: RELEASE_CHECK_URL
              valueFrom:
                configMapKeyRef:
                  key: RELEASE_CHECK_URL
                  name: env-netbox-env
            # configMap -> secret
            - name: SECRET_KEY
              valueFrom:
                secretKeyRef:
                  key: SECRET_KEY
                  name: env-netbox-env
            - name: SKIP_SUPERUSER
              valueFrom:
                configMapKeyRef:
                  key: SKIP_SUPERUSER
                  name: env-netbox-env
            # configMap -> secret
            - name: SUPERUSER_API_TOKEN
              valueFrom:
                secretKeyRef:
                  key: SUPERUSER_API_TOKEN
                  name: env-netbox-env
            - name: SUPERUSER_EMAIL
              valueFrom:
                configMapKeyRef:
                  key: SUPERUSER_EMAIL
                  name: env-netbox-env
            - name: SUPERUSER_NAME
              valueFrom:
                configMapKeyRef:
                  key: SUPERUSER_NAME
                  name: env-netbox-env
            # configMap -> secret
            - name: SUPERUSER_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: SUPERUSER_PASSWORD
                  name: env-netbox-env
            - name: WEBHOOKS_ENABLED
              valueFrom:
                configMapKeyRef:
                  key: WEBHOOKS_ENABLED
                  name: env-netbox-env
            # Added for TZ
            - name: TIME_ZONE
              valueFrom:
                configMapKeyRef:
                  key: TIME_ZONE
                  name: env-netbox-env
          # Fixed version
          image: netboxcommunity/netbox:v3.4-2.4.0
          #livenessProbe:
          #  exec:
          #    command:
          #      - ps -aux | grep -v grep | grep -q rqworker || exit 1
          #  initialDelaySeconds: 20
          #  periodSeconds: 15
          #  timeoutSeconds: 3
          name: netbox-worker
          resources: {}
          volumeMounts:
            - mountPath: /etc/netbox/config
              name: netbox-worker-claim0
              readOnly: true
            - mountPath: /etc/netbox/reports
              name: netbox-worker-claim1
              readOnly: true
            - mountPath: /etc/netbox/scripts
              name: netbox-worker-claim2
              readOnly: true
            - mountPath: /opt/netbox/netbox/media
              name: netbox-media-files
      restartPolicy: Always
      volumes:
        - name: netbox-worker-claim0
          persistentVolumeClaim:
            # Integrated netbox-claim
            claimName: netbox-claim0
            readOnly: true
        - name: netbox-worker-claim1
          persistentVolumeClaim:
            # Integrated netbox-claim
            claimName: netbox-claim1
            readOnly: true
        - name: netbox-worker-claim2
          persistentVolumeClaim:
            # Integrated netbox-claim
            claimName: netbox-claim2
            readOnly: true
        - name: netbox-media-files
          persistentVolumeClaim:
            claimName: netbox-media-files
#status: {}

POD

PVC 특성 상 권한의 문제도 있고, config가 따로 없다 보니 config에 대해 initializing이 필요하여 busybox 이미지를 통해 config를 옮겨주는 작업이 필요하다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37

# New [busybox.yaml]
dor1@is-master:~/netbox/kompose$ vi busybox.yaml
apiVersion: v1
kind: Pod
metadata:
  name: busybox
  namespace: netbox
spec:
  containers:
    - name: config
      image: busybox:latest
      command: ["sleep", "3600" ]
      volumeMounts:
        - mountPath: /mnt
          name: netbox-claim0
    - name: reports
      image: busybox:latest
      command: ["sleep", "3600" ]
      volumeMounts:
        - mountPath: /mnt
          name: netbox-claim1
    - name: scripts
      image: busybox:latest
      command: ["sleep", "3600" ]
      volumeMounts:
        - mountPath: /mnt
          name: netbox-claim2
  volumes:
    - name: netbox-claim0
      persistentVolumeClaim:
        claimName: netbox-claim0
    - name: netbox-claim1
      persistentVolumeClaim:
        claimName: netbox-claim1
    - name: netbox-claim2
      persistentVolumeClaim:
        claimName: netbox-claim2

설정이 완료되었으면, config 값에 대해 busybox의 이미지를 이용하여 옮겨준다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55

# configMap
dor1@is-master:~/netbox/kompose$ kubectl apply -f env-netbox-env-configmap.yaml
configmap/env-netbox-env created

# secret
dor1@is-master:~/netbox/kompose$ kubectl apply -f env-netbox-env-secret.yaml
secret/env-netbox-env created

# networkPolicy
dor1@is-master:~/netbox/kompose$ kubectl apply -f netbox-default-networkpolicy.yaml
networkpolicy.networking.k8s.io/netbox-default created

# PVC
dor1@is-master:~/netbox/kompose$ kubectl apply -f netbox-persistentvolumeclaim.yaml -f netbox-media-files-persistentvolumeclaim.yaml
persistentvolumeclaim/netbox-claim0 created
persistentvolumeclaim/netbox-claim1 created
persistentvolumeclaim/netbox-claim2 created
persistentvolumeclaim/netbox-media-files created

# busybox POD
dor1@is-master:~/netbox/kompose$ kubectl apply -f busybox.yaml
pod/busybox created

dor1@is-master:~/netbox/kompose$ kubectl get pod -n netbox busybox
NAME      READY   STATUS    RESTARTS   AGE
busybox   3/3     Running   0          2m30s

## config 이동
### config
dor1@is-master:~/netbox/kompose$ cd ..
dor1@is-master:~/netbox$ kubectl cp -n netbox ./configuration busybox:/mnt -c config
dor1@is-master:~/netbox$ kubectl exec -n netbox busybox -c config -- sh -c "mv /mnt/configuration/* /mnt && rm -rf /mnt/configuration"
dor1@is-master:~/netbox$ kubectl exec -n netbox busybox -c config -- sh -c "ls /mnt"
configuration.py
extra.py
ldap
logging.py
plugins.py

### reports
dor1@is-master:~/netbox$ kubectl cp -n netbox ./reports busybox:/mnt -c reports
dor1@is-master:~/netbox$ kubectl exec -n netbox busybox -c reports -- sh -c "mv /mnt/reports/* /mnt && rm -rf /mnt/reports"
dor1@is-master:~/netbox$ kubectl exec -n netbox busybox -c reports -- sh -c "ls /mnt"
devices.py.example

### scripts
dor1@is-master:~/netbox$ kubectl cp -n netbox ./scripts busybox:/mnt -c scripts
dor1@is-master:~/netbox$ kubectl exec -n netbox busybox -c scripts -- sh -c "mv /mnt/scripts/* /mnt && rm -rf /mnt/scripts"
dor1@is-master:~/netbox$ kubectl exec -n netbox busybox -c scripts -- sh -c "ls /mnt"
__init__.py

## Delete busybox POD
dor1@is-master:~/netbox$ cd kompose
dor1@is-master:~/netbox/kompose$ kubectl delete -f busybox.yaml
pod "busybox" deleted

Deployment항목은 service가 올라가야 서로 host를 찾을 수 있기 때문에 뒤쪽의 service 항목을 먼저 올린 뒤에 작업 해준다.

4. NetBox-Housekeeping

netbox-housekeeping은 다음과 같이 지원 해준다.

  • 인증 세션 만료된 DB 정리
  • 오래된 changelog 삭제
  • 오래된 job result에 대한 정리
  • NetBox release(신버전) 체크

https://github.com/netbox-community/netbox/blob/develop/docs/administration/housekeeping.md

PVC

설정 값이 저장되어있는 NetBox에서 만든 PVC를 그대로 이용하므로 필요가 없다.

1
2

# Delete PVC yaml
dor1@is-master:~/netbox/kompose$ rm netbox-housekeeping-claim[0-2]-persistentvolumeclaim.yaml

Deployment

NetBox에서 만들어진 PVC를 이용하기 위하여 PVC는 netbox-claim으로 변경해준다.
이미지의 버전은 fix 시킨다.
k8s 특성 상 liveness(docker의 helathcheck와 유사한 기능)은 새로 path를 설정 해줘야 하며, 필요 없을 시에는 사용할 필요가 없다. (기본 이미지로 진행하게 되면 기본적으로 설정 되어있어Events의 항목에 error가 지속적으로 발생함)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299

# netbox-housekeeping-deployment.yaml
dor1@is-master:~/netbox/kompose$ netbox-housekeeping-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  #annotations:
  #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
  #  kompose.version: 1.28.0 (c4137012e)
  #creationTimestamp: null
  labels:
    io.kompose.service: netbox-housekeeping
  name: netbox-housekeeping
  # Add namespace
  namespace: netbox
spec:
  replicas: 1
  selector:
    matchLabels:
      io.kompose.service: netbox-housekeeping
  strategy:
    type: Recreate
  template:
    metadata:
      #annotations:
      #  kompose.cmd: kompose convert -f docker-compose.yml -o kompose
      #  kompose.version: 1.28.0 (c4137012e)
      #creationTimestamp: null
      labels:
        io.kompose.network/netbox-default: "true"
        io.kompose.service: netbox-housekeeping
    spec:
      containers:
        - args:
            - /opt/netbox/housekeeping.sh
          env:
            - name: CORS_ORIGIN_ALLOW_ALL
              valueFrom:
                configMapKeyRef:
                  key: CORS_ORIGIN_ALLOW_ALL
                  name: env-netbox-env
            - name: DB_HOST
              valueFrom:
                configMapKeyRef:
                  key: DB_HOST
                  name: env-netbox-env
            # Added for DB_PORT
            - name: DB_PORT
              valueFrom:
                configMapKeyRef:
                  key: DB_PORT
                  name: env-netbox-env
            - name: DB_NAME
              valueFrom:
                configMapKeyRef:
                  key: DB_NAME
                  name: env-netbox-env
            - name: DB_USER
              valueFrom:
                configMapKeyRef:
                  key: DB_USER
                  name: env-netbox-env
            # configMap -> secret
            # Used env-postgres-env
            - name: DB_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: POSTGRES_PASSWORD
                  name: env-postgres-env
            - name: EMAIL_FROM
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_FROM
                  name: env-netbox-env
            # configMap -> secret
            - name: EMAIL_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: EMAIL_PASSWORD
                  name: env-netbox-env
            - name: EMAIL_PORT
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_PORT
                  name: env-netbox-env
            - name: EMAIL_SERVER
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_SERVER
                  name: env-netbox-env
            - name: EMAIL_SSL_CERTFILE
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_SSL_CERTFILE
                  name: env-netbox-env
            - name: EMAIL_SSL_KEYFILE
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_SSL_KEYFILE
                  name: env-netbox-env
            - name: EMAIL_TIMEOUT
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_TIMEOUT
                  name: env-netbox-env
            - name: EMAIL_USERNAME
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_USERNAME
                  name: env-netbox-env
            - name: EMAIL_USE_SSL
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_USE_SSL
                  name: env-netbox-env
            - name: EMAIL_USE_TLS
              valueFrom:
                configMapKeyRef:
                  key: EMAIL_USE_TLS
                  name: env-netbox-env
            - name: GRAPHQL_ENABLED
              valueFrom:
                configMapKeyRef:
                  key: GRAPHQL_ENABLED
                  name: env-netbox-env
            - name: HOUSEKEEPING_INTERVAL
              valueFrom:
                configMapKeyRef:
                  key: HOUSEKEEPING_INTERVAL
                  name: env-netbox-env
            - name: MEDIA_ROOT
              valueFrom:
                configMapKeyRef:
                  key: MEDIA_ROOT
                  name: env-netbox-env
            - name: METRICS_ENABLED
              valueFrom:
                configMapKeyRef:
                  key: METRICS_ENABLED
                  name: env-netbox-env
            - name: REDIS_CACHE_DATABASE
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_DATABASE
                  name: env-netbox-env
            - name: REDIS_CACHE_HOST
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_HOST
                  name: env-netbox-env
            # Added for REDIS_CACHE_PORT
            - name: REDIS_CACHE_PORT
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_PORT
                  name: env-netbox-env
            - name: REDIS_CACHE_INSECURE_SKIP_TLS_VERIFY
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_INSECURE_SKIP_TLS_VERIFY
                  name: env-netbox-env
            # configMap -> secret
            # REDIS_CACHE_PASSWROD -> REDIS_PASSWORD
            # Used env-redis-cache-env
            - name: REDIS_CACHE_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: REDIS_PASSWORD
                  name: env-redis-cache-env
            - name: REDIS_CACHE_SSL
              valueFrom:
                configMapKeyRef:
                  key: REDIS_CACHE_SSL
                  name: env-netbox-env
            - name: REDIS_DATABASE
              valueFrom:
                configMapKeyRef:
                  key: REDIS_DATABASE
                  name: env-netbox-env
            - name: REDIS_HOST
              valueFrom:
                configMapKeyRef:
                  key: REDIS_HOST
                  name: env-netbox-env
            # Added for REDIS_PORT
            - name: REDIS_PORT
              valueFrom:
                configMapKeyRef:
                  key: REDIS_PORT
                  name: env-netbox-env
            - name: REDIS_INSECURE_SKIP_TLS_VERIFY
              valueFrom:
                configMapKeyRef:
                  key: REDIS_INSECURE_SKIP_TLS_VERIFY
                  name: env-netbox-env
            # configMap -> secret
            # Used env-redis-env
            - name: REDIS_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: REDIS_PASSWORD
                  name: env-redis-env
            - name: REDIS_SSL
              valueFrom:
                configMapKeyRef:
                  key: REDIS_SSL
                  name: env-netbox-env
            - name: RELEASE_CHECK_URL
              valueFrom:
                configMapKeyRef:
                  key: RELEASE_CHECK_URL
                  name: env-netbox-env
            # configMap -> secret
            - name: SECRET_KEY
              valueFrom:
                secretKeyRef:
                  key: SECRET_KEY
                  name: env-netbox-env
            - name: SKIP_SUPERUSER
              valueFrom:
                configMapKeyRef:
                  key: SKIP_SUPERUSER
                  name: env-netbox-env
            # configMap -> secret
            - name: SUPERUSER_API_TOKEN
              valueFrom:
                secretKeyRef:
                  key: SUPERUSER_API_TOKEN
                  name: env-netbox-env
            - name: SUPERUSER_EMAIL
              valueFrom:
                configMapKeyRef:
                  key: SUPERUSER_EMAIL
                  name: env-netbox-env
            - name: SUPERUSER_NAME
              valueFrom:
                configMapKeyRef:
                  key: SUPERUSER_NAME
                  name: env-netbox-env
            # configMap -> secret
            - name: SUPERUSER_PASSWORD
              valueFrom:
                secretKeyRef:
                  key: SUPERUSER_PASSWORD
                  name: env-netbox-env
            - name: WEBHOOKS_ENABLED
              valueFrom:
                configMapKeyRef:
                  key: WEBHOOKS_ENABLED
                  name: env-netbox-env
            # Added for TZ
            - name: TIME_ZONE
              valueFrom:
                configMapKeyRef:
                  key: TIME_ZONE
                  name: env-netbox-env
          # Fixed version
          image: netboxcommunity/netbox:v3.4-2.4.0
          #livenessProbe:
          #  exec:
          #    command:
          #      - ps -aux | grep -v grep | grep -q housekeeping || exit 1
          #  initialDelaySeconds: 20
          #  periodSeconds: 15
          #  timeoutSeconds: 3
          name: netbox-housekeeping
          resources: {}
          volumeMounts:
            - mountPath: /etc/netbox/config
              name: netbox-housekeeping-claim0
              readOnly: true
            - mountPath: /etc/netbox/reports
              name: netbox-housekeeping-claim1
              readOnly: true
            - mountPath: /etc/netbox/scripts
              name: netbox-housekeeping-claim2
              readOnly: true
            - mountPath: /opt/netbox/netbox/media
              name: netbox-media-files
      restartPolicy: Always
      volumes:
        - name: netbox-housekeeping-claim0
          persistentVolumeClaim:
            # Integrated netbox-claim
            claimName: netbox-claim0
            readOnly: true
        - name: netbox-housekeeping-claim1
          persistentVolumeClaim:
            # Integrated netbox-claim
            claimName: netbox-claim1
            readOnly: true
        - name: netbox-housekeeping-claim2
          persistentVolumeClaim:
            # Integrated netbox-claim
            claimName: netbox-claim2
            readOnly: true
        - name: netbox-media-files
          persistentVolumeClaim:
            claimName: netbox-media-files
#status: {}

Deployment항목은 service가 올라가야 서로 host를 찾을 수 있기 때문에 뒤쪽의 service 항목을 먼저 올린 뒤에 작업 해준다.

rook-ceph을 이용한 NetBox Deployment

1. Service

각각의 host를 찾기 위해서 service 항목을 새로 만들어준다.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55

dor1@is-master:~/netbox/kompose$ vi netbox-service.yaml
apiVersion: v1
kind: Service
metadata:
  name: redis
  namespace: netbox
spec:
  selector:
    io.kompose.service: redis
  ports:
  - protocol: TCP
    port: 6379
    targetPort: 6379
---
apiVersion: v1
kind: Service
metadata:
  name: redis-cache
  namespace: netbox
spec:
  selector:
    io.kompose.service: redis-cache
  ports:
  - protocol: TCP
    port: 6379
    targetPort: 6379
---
apiVersion: v1
kind: Service
metadata:
  name: postgres
  namespace: netbox
spec:
  selector:
    io.kompose.service: postgres
  ports:
  - protocol: TCP
    port: 5432
    targetPort: 5432
---
apiVersion: v1
kind: Service
metadata:
  name: netbox
  namespace: netbox
spec:
  ports:
  - name: http
    nodePort: 30200
    port: 8080
    protocol: TCP
    targetPort: 8080
  selector:
    io.kompose.service: netbox
  type: NodePort

2. NetBox Deployment

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74

dor1@is-master:~/netbox/kompose$ kubectl apply -f netbox-service.yaml
service/redis created
service/redis-cache created
service/postgres created
service/netbox created

dor1@is-master:~/netbox/kompose$ kubectl apply -f netbox-worker-deployment.yaml
deployment.apps/netbox-worker created

dor1@is-master:~/netbox/kompose$ kubectl get pod -n netbox
NAME                                  READY   STATUS    RESTARTS   AGE
netbox-worker-744d87586c-qlkpd        1/1     Running   0          22m
postgres-964c6f654-8c75l              1/1     Running   0          35m
redis-6dbdf5685f-7gc72                1/1     Running   0          35m
redis-cache-79864b7b6-5th8v           1/1     Running   0          35m

dor1@is-master:~/netbox/kompose$ kubectl apply -f netbox-deployment.yaml
deployment.apps/netbox created

dor1@is-master:~/netbox/kompose$ kubectl get pod -n netbox
NAME                                  READY   STATUS    RESTARTS   AGE
netbox-59895cb669-znmpl               1/1     Running   0          12m
netbox-worker-744d87586c-qlkpd        1/1     Running   0          34m
postgres-964c6f654-8c75l              1/1     Running   0          47m
redis-6dbdf5685f-7gc72                1/1     Running   0          47m
redis-cache-79864b7b6-5th8v           1/1     Running   0          47m

dor1@is-master:~/netbox/kompose$ kubectl apply -f netbox-housekeeping-deployment.yaml
deployment.apps/netbox-housekeeping created

dor1@is-master:~/netbox/kompose$ kubectl get pod -n netbox
NAME                                  READY   STATUS    RESTARTS   AGE
netbox-59895cb669-znmpl               1/1     Running   0          22m
netbox-housekeeping-74d8d75d9-lzmnm   1/1     Running   0          10m
netbox-worker-744d87586c-qlkpd        1/1     Running   0          44m
postgres-964c6f654-8c75l              1/1     Running   0          57m
redis-6dbdf5685f-7gc72                1/1     Running   0          57m
redis-cache-79864b7b6-5th8v           1/1     Running   0          57m

dor1@is-master:~/netbox/kompose$ kubectl get cm,secret,pvc,pod,deployments -n netbox
NAME                         DATA   AGE
configmap/env-netbox-env     33     74m
configmap/kube-root-ca.crt   1      2d22h

NAME                         TYPE     DATA   AGE
secret/env-netbox-env        Opaque   4      74m
secret/env-postgres-env      Opaque   5      3h19m
secret/env-redis-cache-env   Opaque   1      76m
secret/env-redis-env         Opaque   1      76m

NAME                                            STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   AGE
persistentvolumeclaim/netbox-claim0             Bound    pvc-918aaf9f-db84-435e-8e41-fb0e7e53cebd   50Gi       RWX            rook-cephfs    74m
persistentvolumeclaim/netbox-claim1             Bound    pvc-4d8b8b08-03e3-4047-92ea-4eb7ef9a3738   50Gi       RWX            rook-cephfs    74m
persistentvolumeclaim/netbox-claim2             Bound    pvc-767ad8f6-ca7f-4a9d-b44f-863e4a9f70b9   50Gi       RWX            rook-cephfs    74m
persistentvolumeclaim/netbox-media-files        Bound    pvc-5e17f6aa-a6b7-4d5f-bec6-3f345bd6a4b7   500Gi      RWO            rook-cephfs    74m
persistentvolumeclaim/netbox-postgres-data      Bound    pvc-ecce50a4-a54c-48e3-ad88-54b5fefeecfd   500Gi      RWO            rook-cephfs    76m
persistentvolumeclaim/netbox-redis-cache-data   Bound    pvc-8c4bb301-5b88-48b3-9eb2-3f7c51629481   50Gi       RWO            rook-cephfs    76m
persistentvolumeclaim/netbox-redis-data         Bound    pvc-e2d0560d-d9e6-4eda-a3c8-3541497f7a72   50Gi       RWO            rook-cephfs    76m

NAME                                      READY   STATUS    RESTARTS   AGE
pod/netbox-59895cb669-znmpl               1/1     Running   0          52m
pod/netbox-housekeeping-74d8d75d9-lzmnm   1/1     Running   0          20m
pod/netbox-worker-744d87586c-qlkpd        1/1     Running   0          53m
pod/postgres-964c6f654-8c75l              1/1     Running   0          76m
pod/redis-6dbdf5685f-7gc72                1/1     Running   0          76m
pod/redis-cache-79864b7b6-5th8v           1/1     Running   0          76m

NAME                                  READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/netbox                1/1     1            1           52m
deployment.apps/netbox-housekeeping   1/1     1            1           20m
deployment.apps/netbox-worker         1/1     1            1           53m
deployment.apps/postgres              1/1     1            1           76m
deployment.apps/redis                 1/1     1            1           76m
deployment.apps/redis-cache           1/1     1            1           76m

Deployment가 다 끝나면 접속해보면 정상적으로 접속이 된다.

NetBox 초기 화면 NetBox 초기 화면

초기 계정은 admin/admin 이다.

추가 사항

1. Secret 사용 시 필수 사항

Secret 사용 시에는 기본적으로 base64의 암호화 되어있는 값(vaule)만 들어가야 한다.
즉, 다음과 같이 base64로 encoding 하여서 입력한다.
추가로 line break(\n) 항목이 들어가는 것을 피하기 위하여 반드시 -n 옵션을 넣어서 입력한다.

1
2

dor1@is-master:~/netbox/kompose$ echo -n 'admin' | base64
YWRtaW4=
Cluster, Kubernetes
cluster kubernetes netbox kompose
This post is licensed under CC BY 4.0 by the author.
